Gamedeploymenttemplate

The GameDeploymentTemplate indicates which [game server] ApplicationBuilds you want to have deployed within a Fleet.

Figure 1: Highlighting where the GameDeploymentTemplate elements belong in the overview

Usage

A GameDeploymentTemplate is used by a Fleet and defines which ApplicationBuilds (of type Game) will be deployed for that Fleet. A single GameDeploymentTemplate can define more than one ApplicationBuild by adding multiple GameDeploymentTemplateBuild elements. Each of these defines a single (ApplicationBuild (of type Game).

Each ApplicationBuild defined in a template will be treated like individually scalable builds. If you set a Fleet's operational status to "Automatic Deployment", each build will be deployed individually according to the DeploymentProfile.minimumCapacity value. Similarly, when you set the Fleet's operational status to "Automatic Scaling", each build will be automatically scaled individually. In short, each ApplicationBuild in the GameDeploymentTemplate is treated individually. No relationship between the defined ApplicationBuilds exists.

You can create as many GameDeploymentTemplates as you like within the platform. However, a Fleet can only point to one GameDeploymentTemplate at a time. A GameDeploymentTemplate can be shared (re-used) across multiple fleets though.

Element structure

Property	Value type	Required	Description
id	string	Read-only	Unique identifier of this element
fleetIds	[int]	Read-only	List of Fleet IDs this template is used in
name	string	Yes	Name of the template
inUse	boolean	Read-only	Indicates whether this template is actively being used in a Fleet
createdAt	int	Read-only	A unix timestamp of when this element was created
gameDeploymentTemplateBuild	[GameDeploymentTemplateBuild]	Yes	List of GameDeploymentTemplateBuild elements, pointing to ApplicationBuilds

Table 1: GameDeploymentTemplate element structure

GameDeploymentTemplateBuild element structure

Property	Value type	Required	Description
applicationBuildId	string	Yes	Identifier of the ApplicationBuild you want to deploy

Table 2: GameDeploymentTemplateBuild element structure

API example

Create a new GameDeploymentTemplate within your i3D.net account.

Full API reference

HTTP request

POST /v3/deploymentTemplate/game

Request body

{
  "name": "MyGameDeploymentTemplate",
  "gameDeploymentTemplateBuild": [
    {
      "applicationBuildId": "3776948653267321543"
    }
  ]
}

Response body

[
  {
    "id": "6537333393893172977",
    "fleetIds": [
      0
    ],
    "name": "MyGameDeploymentTemplate",
    "inUse": 0,
    "createdAt": 1573060361,
    "gameDeploymentTemplateBuild": [
      {
        "applicationBuildId": "3776948653267321543"
      }
    ]
  }
]

Attach GameDeploymentTemplate to a Fleet:

Full API reference

HTTP request

PUT /v3/fleet/{fleetId}

Request body

{
  "gameDeploymentTemplateId": "6537333393893172977",
}

Response body

[
  {
    "id": "string",
    "name": "string",
    "deploymentEnvironmentId": "string",
    "deploymentProfileId": "string",
    "gameDeploymentTemplateId": "6537333393893172977",
    "utilityDeploymentTemplateId": "string",
    "operationalStatus": 0
  }
]
